NKNShell Malware Distributed via VPN Website
AhnLab SEcurity intelligence Center (ASEC) has confirmed that malware has been uploaded to the website of a South Korean VPN provider. Based on the distribution method and characteristics of the malware used, this attack appears to be the work of the same threat actor who has been targeting South Korean VPN providers since 2023. In previous cases, the attacker ultimately installed backdoors such as SparkRAT, MeshAgent, and Sliver to control the infected systems. In the latest incident, MeshAgent with similar PDB paths was again observed, along with a newly identified backdoor named NKNShell. NKNShell is notable for using NKN and MQTT protocols for communication with its C&C server.
- SparkRAT Being Distributed Within a Korean VPN Installer
- Analysis of Attack Cases: From Korean VPN Installations to MeshAgent Infections
- Sliver C2 Being Distributed Through Korean Program Development Company
1. Malware Distribution
As of November 2025, malware is still being downloaded from the Korean VPN provider’s website. When the downloaded archive is extracted and executed, the legitimate VPN installation proceeds while simultaneously using PowerShell to download and execute a PowerShell script. This script installs various malware, including the NKNShell backdoor, MeshAgent, and gs-netcat. This article will analyze the malware according to each flow.
Figure 1. Downloaded from the Korean VPN provider’s website
2. Malware Analysis
2.1. Trojanized Installer
Figure 2. Flowchart
The installer is written in Go and signed with an invalid certificate impersonating NVIDIA. It checks for virtual machine environments using code borrowed from GoDefender [1]. [1] Afterward, it executes itself as a child process with a PowerShell download command as an argument. The child process downloads PowerShell, loads it into memory, and runs Base64-encoded commands.
PowerShell is a PowerShell console developed in C/C++, which disables security features such as AMSI. This allows attackers to bypass detection by utilizing AMSI when executing commands using PowerShell. Commands executed through PowerShell are responsible for downloading and executing the “sql-auto.ps1” script from external sources.
2.2. PowerShell Downloader Script – 1 (sql-auto.ps1)
The “sql-auto.ps1” script acts as a downloader for additional malware. Evidence suggests the attacker used generative AI to create the malware, which applies not only to executable malware but also to PowerShell scripts.
Figure 3. Comment string that is suspected to have been written by AI
The “sql-auto.ps1” script has various features, but many of them are commented out and not working. The script attempts to disable Windows Defender, add exclusion paths, and execute the “Null-AMSI” script developed by BlackShell256 to bypass AMSI. [2] The most important feature of “sql-auto.ps1” is downloading additional payloads from external sources. There are two types of downloads: one for SQLMap malware (currently commented out) and another downloader script called “install.ps1”.
2.3. PowerShell Downloader Script – 2 (install.ps1)
This script includes functionality to disable Event Tracing for Windows (ETW) using “Invoke-NullAMSI” and registers a WMI filter named “Cleanup” for persistence. The “Cleanup” filter allows executing the actual downloader script it contains. After this process, it terminates the processes that will be injected with malware later on and executes the script directly.
Figure 4. Registered WMI filter and consumer
The script ultimately executed supports 15 UAC bypass techniques, but none of them are actually used. The supported features include known UAC bypass methods such as fodhelper.exe, slui.exe, silentcleaunp task, sdclt.exe, perfmon.exe, eventvwr.exe, compmgmtlauncher.exe, computerdefaults.exe, token manipulation, and cmstp.exe.
The actual function of the script is to download and install the gs-netcat, MeshAgent, and NKNShell backdoors. Additionally, the NKNShell backdoor executes and injects into Microsoft Edge, Notepad, Calculator, and Paint processes.
2.4. MeshAgent
MeshAgent, part of the open-source MeshCentral remote management tool, provides system control commands and remote desktop features (VNC, RDP). Threat actors have been using MeshAgent in their attacks for a long time. MeshAgent used in attacks has been developed by the threat actors themselves and has the following PDB information:
- C:\Users\anfdh\Downloads\MeshAgent-master\MeshAgent-master\Release\MeshService64.pdb
- C:\Users\anfdh\Downloads\MeshAgent-master (1)\MeshAgent-master\Release\MeshService64.pdb
- C:\Users\anfdh\Downloads\MeshAgent-master (2)\MeshAgent-master\Release\MeshService64.pdb
The “new-ms.ps1” script downloads MeshAgent to the “%LOCALAPPDATA%\svchost\services.exe” path and places the “services.msh” configuration file in the same path, so that it uses this configuration. The configuration file contains the C&C server address as shown below.
Figure 5. Configuration file containing the C&C server address
2.5. gs-netcat
gs-netcat, part of Global Socket tools, uses the Global Socket Relay Network (GSRN) for communication. gs-netcat is the GSRN version of netcat, and it can communicate using a configured password even when it is located in an internal network.
The “gsocks.ps1” script downloads the “file.zip” compressed file and decompresses it in the “c:\windows\linux” directory, including gs-netcat as “cached.exe”. It also creates “windows.sh” and executes it using bash.exe. The password for gs-netcat is set in “windows.sh”. Threat actors can access the infected system from external sources using this password. In other words, the “gsocks.ps1” script is responsible for installing the remote shell using gs-netcat.
Figure 6. Installation path and execution script of gs-netcat
Additionally, the behavior of executing the “windows.sh” script using “bash.exe” is registered as a task named “Windows Linux System,” ensuring its persistence. Furthermore, the system’s basic information, including the password for gs-netcat, is transmitted to the C&C server (threat actor) via PowerShell commands.
Figure 7. Log transmission routine
2.6. NKNShell
The malware installed and executed under the name PX.exe is a backdoor written in the Go programming language. Based on Go functions and strings such as “NKN Shell Client,” it is clear that the malware author named it NKNShell. NKN stands for New Kind of Network, a blockchain-based P2P networking protocol. In practice, the malware uses not only the NKN protocol but also MQTT (Message Queueing Telemetry Transport) for communication with its C&C server.
One notable characteristic of NKNShell is that it appears to have been developed using AI tools. Similar to the previously analyzed PowerShell scripts, the binary contains Korean-language comments, and the presence of emojis suggests that the developer leveraged generative AI during its creation.
Figure 8. Comment string included in the binary
A. C&C Communication
NKNShell, developed in Go, uses the NKN and MQTT protocols to communicate with its C&C server and receive commands. The use of the blockchain-based P2P networking protocol NKN for C&C communication has been seen before in malware such as NKAbuse and the open-source malware NGLite. The malware generates a unique ID, an NKN address, which is then used to connect to the Seed node. After establishing this connection, the malware sends collected information to attacker-controlled addresses that are hardcoded into the binary.
Figure 9. Request packet to the seed node
NKNShell also uses the MQTT messaging protocol alongside NKN for communication with its C&C server. It first connects to specific MQTT brokers, using the same Client ID generated during the NKN process. During the connection, it sends a Will message (LTW: Last Will & Testament) to a designated topic. Similar to the NKN protocol, the malware transmits system information collected from the infected host. As a result, any attacker subscribed to that topic can later retrieve detailed information about the compromised system.
- MQTT Broker Address – 1: broker.emqx[.]io:1833
- MQTT Broker Address – 2: broker.hivemq[.]com:1833
- MQTT Broker Address – 3: broker.mqtt[.]cool:1833
- MQTT Broker Address – 4: broker.mosquitto[.]org:1833
Figure 10. Packet in the process of connecting to the MQTT broker
Additionally, NKNShell utilizes the Client ID to compute an MD5 hash and subscribes to a topic named after that hash. The attacker, having received the Client ID from the Will message, can determine which MD5-based topic the infected system is subscribed to. This allows the attacker to publish commands to that topic, effectively delivering instructions to the compromised host.
| Item | Information |
|---|---|
| arch | Architecture |
| cpuusage | CPU usage |
| hostinfo | Computer name |
| isadmin | Administrator privileges |
| lanip | IP address |
| mac | MAC address |
| num_cpu | Number of CPU cores |
| os | Operating system |
| osinfo | Operating system information (Windows version, etc.) |
| pathinfo | Malware path |
| ram | RAM information |
| username | User name |
| version | 1.0.7 |
| wanip | External IP |
Table 1. List of information transmitted
B. Supported Commands
NKNShell receives the following commands via NKN and MQTT protocols. These commands include typical backdoor functionalities such as information gathering and remote control, similar to what most backdoors support. However, some features appear to be only partially implemented or not fully functional.
| Command | Description |
|---|---|
| ps | Retrieve process list |
| bof | Execute BOF (Beacon Object File) |
| rem | Remote proxy |
| ping | Ping |
| attack | DDoS attack commands (tcp, udp, http flood) |
| config | Download configuration |
| command | Execute command |
| sideload | DLL sideloading |
| spawndll | Load DLL into memory |
| file_list | Retrieve file list |
| injection | Code injection |
| migration | Not implemented |
| clear_log | Delete event, registry, and Prepatch logs |
| execution | Execute command |
| disconnect | Disconnect |
| execute_pe | Execute PE from memory |
| screenshot | Capture screenshot |
| codesigning | Not implemented |
| steal_token | Steal token |
| file_delete | Delete file |
| file_upload | Upload file |
| file_execute | Execute file |
| clone_session | Clone session |
| file_download | Download file |
| inject_process | Inject into process |
| postmsf_cshrp | Not implemented |
| set_encryption | Enable message encryption |
| execute_csharp | Execute assembly |
| python | Execute Python script |
| get_systeminfo | Collect system info (architecture, CPU, OS version, etc.) |
| ps_session_exec | Execute PowerShell session |
| execute_assembly | Execute assembly |
| impersonate_user | Impersonate user |
| ps_session_start | Start PowerShell session |
| ps_session_stop | Stop PowerShell session |
| execute_shellcode | Execute shellcode |
| enumerate_sessions | Enumerate sessions |
| execute_powershell | Execute PowerShell |
| hijack_codesigning | Spoof code signing |
| migrate_cobaltstrike | Not implemented |
| process_manipulation | Process manipulation (inject DLL, memory dump, hijack token, kill, resume, suspend) |
| execute_charp_bypass | Not implemented |
| inject_system_process | Inject into system process |
| spoof_microsoft_signature | Not implemented |
Table 2. Commands supported by NKNShell
Figure 11. Receiving the ping command in the MQTT protocol
C. Update
Instead of using standard commands for updates, NKNShell leverages an alternative infrastructure. It uses additional C&C servers or anonymous blogging platforms such as Telegraph (telegra[.]ph, te.legra[.]ph, graph[.]org). The malware periodically selects one of these domains at random, appends a URL, and connects to it.
When accessed, the page displays a Base64-encoded string uploaded by the attacker. Decoding this Base64 string reveals the URL of the payload for the malware update.
Figure 12. Update address uploaded to the Telegram
2.7. SQLMap Malware
Although it was commented out in the PowerShell script at the time of analysis, ‘main.exe’—that is, the SQLMap malware—was actually used in the real attack. SQLMap is an open-source tool designed to test web applications for SQL injection vulnerabilities on specified URLs provided as arguments. When the SQLMap malware runs, it creates a folder named named “sqlmap-win64” in the same directory and installs the SQLMap tool there.
Figure 13. Log showing the execution of the SQLMap malware
It is likely that the scanning target addresses are then received from another C&C server. The fact that messages are being published to a specific MQTT topic continuously suggests that the scanning results are being transmitted to this topic.
3. Conclusion
The Larva-24010 threat actor is distributing malware through the website of a Korean VPN service provider. As a result, when a user downloads and runs the installer from the VPN website, malware can be installed on the system. Since at least 2023, the Larva-24010 threat actor has been targeting Korean VPN users to spread malware, ultimately installing various backdoors such as MeshAgent, gs-netcat, and NKNShell. Through this, the attacker can control infected systems where the VPN is installed and steal sensitive information stored on those systems.
