ASEC (AhnLab Security Emergency response Center) has recently discovered the installation of the PlugX malware through the Chinese remote control programs Sunlogin and Awesun’s remote code execution vulnerability.
Sunlogin’s remote code execution vulnerability (CNVD-2022-10270 / CNVD-2022-03672) is still being used for attacks even now ever since its exploit code was disclosed. The team previously made a post about how Sliver C2, XMRig CoinMiner, and Gh0st RAT were being distributed through the Sunlogin RCE vulnerability. Additionally, since Gh0st RAT was developed in China, it is the most common RAT used by threat actors based in China.
AweSun is also a remote control program developed in China and, while its specific vulnerability has not been identified, it is presumed that a similar RCE vulnerability to that of Sunlogin had been disclosed. The same threat actors performed an RCE vulnerability exploitation on both Sunlogin and AweSun to install Sliver C2. A previous blog post has covered the cases that later occurred where similar vulnerability exploitations were used to install the Paradise ransomware.
PlugX is one of the major backdoors used by APT threat groups that are based in China. Its distribution is known to have started in 2008 and is still being used to this day as variants with additional features are being used for attacks. Mustang Panda, Winnti, APT3, and APT41 are the main APT threat groups that have used PlugX in their attacks, and most of them are known to be based in China.
PlugX is a module-based malware that supports various plugins with different features. Therefore, threat actors can perform malicious behaviors such as system control and information theft by using the various features from these plugins.
Another characteristic of PlugX is its use of the DLL side-loading method. The DLL side-loading method involves installing a malicious DLL in the same path as a normal program and using the execution of the normal program to load the malicious DLL, which in turn starts the malicious routine. This is to evade being detected by security products. The normal program becomes the subject performing the malicious behaviors and these behaviors are then recognized as the behaviors of a normal program.
PlugX is usually distributed as a compressed file or a dropper, but, either way, the normal EXE file, the malicious loader DLL that’s going to be used for side-loading with the same filename, and the encoded data files are ultimately created in the same directory. The executable file loads and executes the loader DLL in the same path, which in turn reads and decrypts the data file in the same directory before executing it in the memory. After this process, the malware that is ultimately operating in the memory area is PlugX.
2. PlugX Installed Through Vulnerability Exploitation
ASEC is monitoring attacks against systems with either unpatched vulnerabilities or inappropriately configured settings. Recently, the team confirmed that PlugX is being installed through the RCE vulnerability exploitation of Sunlogin and AweSun.
According to AhnLab’s ASD (AhnLab Smart Defense) log, the team has confirmed that the PowerShell command executed via this vulnerability exploitation creates a file named esetservice.exe.
esetservice.exe is actually the HTTP Server Service program made by the company ESET, meaning its a normal file.
Further investigation into related logs revealed that the threat actor also downloaded a file named http_dll.dll aside from esetservice.exe. Additionally, the following is a log from another system that shows the threat actor not only exploited Sunlogin, but also the AweSun vulnerability in their attack.
During the process of investigating the connection between the two files, it was discovered that the “esetservice.exe” program has a feature that loads the “http_dll.dll” file in the same directory if executed without an additional argument. This is a classic DLL side-loading method, and PlugX is most known for using this method.
PlugX is distributed with the normal exe program, the DLL that acts as the loader, and the data file containing the actual encoded malware, as a set. An analysis of the actual code revealed that the “http_dll.dll” file contains a routine to read the “lang.dat” file that is in the same directory before decrypting and executing it.
3. PlugX Dropper and Loader Analysis
During the analysis of PlugX, malware using the same “esetservice.exe” and “http_dll.dll” files in their attack was found on VirusTotal. This malware is a WinRar Sfx format dropper malware that creates “esetservice.exe,” “http_dll.dll,” and “lang.dat” upon execution. It then runs “esetservice.exe” to ultimately install and execute PlugX. While this dropper was not found in the vulnerability exploitation covered above, considering that PlugX’s C&C address is the same as the download URL used in the vulnerability exploitation, it can be assumed that the same threat actor is behind both attacks.
The PlugX dropper disguises itself as the path of normal programs and creates malware in the “C:\ProgramData\Windows NT\Windows eset service” path. They are also hidden through the properties setting to make them less noticeable by users.
When “esetservice.exe” is executed, it loads the “http_dll.dll” file in the same directory, and consequently executes the DllMain() function of “http_dll.dll”. Instead of directly executing the function for loading the “lang.dat” file, DllMain() modifies the code of “esetservice.exe,” as shown below, before applying a patch so that “esetservice.exe” loads “http_dll.dll” and branches into the “http_dll.dll” loader routine itself.
This routine is responsible for loading the “lang.dat” file in the same directory and executing it in the memory. The beginning part of the “lang.dat” file is a shellcode. When this code is executed, it decrypts PlugX which has been saved with it and executes it in the memory.
4. Analysis of PlugX
As explained above, PlugX is a malware that has gone through continuous updates for more than a decade, so all sorts of variants are being discovered even now. In 2020, a report about the classification and analysis of various PlugX variants was published on Dr.Web.  Security Joes covered the most recently discovered PlugX variants in 2022. The PlugX that is currently being analyzed is almost identical to the BackDoor.PlugX.38 variant that was reported on Dr.Web. Excluding the configuration data, it can be assumed that it is the same as the PlugX on the most recent Security Joes report.
The PlugX used in the attack offers various modes according to the argument given. The following is a process tree that can be found when the PlugX that is currently being analyzed is executed. It can be inferred that the 4 modes, “100”, “200”, “201”, and “209” are executed in order.
When the PlugX dropper is executed for the first time, it creates the files “esetservice.exe”, “http_dll.dll”, and “lang.dat” under the “%PUBLIC%\Downloads\” directory before executing “esetservice.exe”. After being loaded and executed by the “esetservice.exe” process, PlugX uses the create method of WMi’s Win32_Process class to give the argument “100” and execute itself again.
When executed after being given “100” as an argument, the UAC bypass process is started after an injection process. “runonce.exe” is the process that is targeted and injected with a shellcode. The injected shellcode is responsible for abusing the ICMLuaUtil interface to bypass UAC and run the process with admin privileges. “esetservice.exe” is able to run with admin privileges thanks to this. Afterward, it registers itself as a service and sets the argument to “200”. When the process reaches this point, it gives the “runonce.exe” process, which is the target of injection again, the argument “201” before executing and injecting itself. “runonce.exe” then gives the argument “209” to the “msiexec.exe” process responsible for plugins before executing and injecting it. The above procedure means that a different mode is executed according to the argument given. A summary of this is displayed below.
|No argument||Initial execution stage|
|100||UAC bypassing stage|
|201||Main loop #1|
|202||Main loop #2|
The “lang.dat” holds the configuration data as well as the shellcode and the encoded PlugX. The configuration data is also encoded, but it is decoded by the PlugX when it is executed in order to obtain the C&C address and other configuration information. There are 4 C&C server addresses and they are shown below.
The commands supported by PlugX are almost the same as the BackDoor.PlugX.38 version covered on the Dr.Web report, but they are distinguished by the 2 additional commands, namely the entries 0x0B and 0x0C.
|0x01||Transmits collected information|
|0x02||Request command again|
|0x06||Upload configuration data|
|0x07||Update configuration data|
|0x08||No actual purpose|
|0x09||No actual purpose|
|0x0A||Pings port 53 from the transmitted address|
|0x0B||Download and execute files from an external source|
There are 2 additional plugins supported by PlugX in comparison to the previous BackDoor.PlugX.38 version, one that steals information saved to the clipboard and one that is responsible for RDP propagation. More information can be found in the Security Joes report published in December 2022.
|Plugin||Date Time Stamp||Feature|
|Disk||0x20120325||Tasks related to files (File lookup/reading/writing, process execution, etc.)|
|Nethood||0x20120215||Lookup shared network resource information|
|Netstat||0x20120215||Lookup TCP/UDP connection tables and TCP entry settings|
|Process||0x20120204||Lookup processes / modules. Terminate processes|
|RegEdit||0x20120315||Tasks related to registry (Lookup, create, delete, etc.)|
|Screen||0x20120220||Screenshot capture and remote desktop|
|Service||0x20120117||Lookup processes/modules. Terminate processes|
|Shell||0x20120305||Remote control shell (Pipe communication)|
|SQL||0x20120323||Tasks related to SQL (Lookup information, command execution, etc.)|
|Telnet||0x20120225||Run as TELNET server|
|ClipLog||0x20190417||Steals clipboard information|
|RDP||0x20190428||Propagation using the shared RDP folder|
Additionally, it is assumed that the location where the stolen data is saved differs for each malware. For example, contrary to a past report, the stolen clipboard data is saved to the “clang.aif” file and the keylogging data in the “ksys.aif” file, both of which are in the installation directory.
Recently, there have been confirmed cases where various strains of malware were installed on unpatched and vulnerable software. Although Sliver, Paradise ransomware, and CoinMiner are the malware that are typically installed through vulnerability exploitations, the team has recently confirmed the distribution of the PlugX backdoor.
PlugX is one of the main backdoor malware used by APT threat groups based in China. New features are being added to it even to this day as it continues to see steady use in attacks. When the backdoor, PlugX, is installed, threat actors can gain control over the infected system without the knowledge of the user. In turn, this allows various malicious behaviors to be performed such as logging key inputs, taking screenshots, and installing additional malware.
Therefore, users must update their installed software to the latest version to preemptively prevent vulnerability exploitations. Also, V3 should be updated to the latest version so that malware infection can be prevented.
– Malware/Win.Generic.C5387131 (2023.02.24.00)
– Trojan/Win.Loader.C5345891 (2022.12.30.02)
– Data/BIN.Plugx (2023.03.03.03)
Subscribe to AhnLab’s next-generation threat intelligence platform ‘AhnLab TIP’ to check related IOC and detailed analysis information.
